Single-Door Industrial Batch Oven
The ZKMO-2 is a single-door batch oven for industrial material baking and drying. The documented chamber measures W450 × D400 × H400 mm and uses horizontal circulating airflow.
- Single-door chamber with horizontal airflow.
- Digital PID temperature control and electronic timer.
- SUS430 stainless-steel chamber and air duct.
Product Images
Product Introduction
The ZKMO-2 is a single-door batch oven for industrial material baking and drying. The documented chamber measures W450 × D400 × H400 mm and uses horizontal circulating airflow.
The oven has 4 shelf levels, with trays available separately. A digital PID controller sets the heating process and an electronic timer supports timed operation. The documented temperature setting range is ambient to 200 °C.
Provide the material, tray dimensions, batch load and required temperature profile to review the configuration. Identify any process emissions or special installation requirements when requesting a quotation. Final operating conditions and suitability depend on the material and loading arrangement.
Features and Operation
- Single-door chamber with horizontal airflow.
- Digital PID temperature control and electronic timer.
- SUS430 stainless-steel chamber and air duct.
Technical Specifications
- Chamber dimensions
- W450 × D400 × H400 mm
- Shelf levels
- 4
- Temperature range
- Ambient to 200 °C
- Airflow
- Single-sided horizontal
- Timer range
- 0–9999 min
- Power supply
- AC 220 V, single-phase, 50 Hz
- Installed power
- 3.5 kW
Specifications describe the documented configuration. Confirm the final configuration for your application.
