Product Category

UV Processing Equipment

UV processing equipment for curing, exposure, surface activation and related material-treatment operations, configured around wavelength, working width and line speed.

Available Product Templates

31 products
1200 mm LED UV Curing Conveyor ZKLED-1200-300

UV Processing Equipment · ZKLED-1200-300

1200 mm LED UV Curing Conveyor

The ZKLED-1200-300 provides LED UV curing for touch-panel full-lamination and post-print processes across a 1200 mm curing width.

View product
PCB UV Curing Conveyor ZKUV-1204

UV Processing Equipment · ZKUV-1204

PCB UV Curing Conveyor

Conveyor UV curing equipment for printed PCBs, with a 1000 mm working width and four metal-halide lamps.

View product
UV Curing Machine for Round Containers ZKUV-202

UV Processing Equipment · ZKUV-202

UV Curing Machine for Round Containers

The ZKUV-202 is a UV drying machine for round containers. Fixtures on a stainless-steel chain conveyor carry the containers through the UV section. The fixtures rotate through 360 degrees in that section, with a UV lamp installed on each side.

View product
F300S UV Curing Conveyor ZKUV-F300S

UV Processing Equipment · ZKUV-F300S

F300S UV Curing Conveyor

The ZKUV-F300S is a UV curing conveyor with a documented 150 mm effective width and an F300S light source using a D bulb.

View product
405 nm LED Curing Conveyor ZKED-3015H

UV Processing Equipment · ZKED-3015H

405 nm LED Curing Conveyor

The ZKED-3015H is an LED curing conveyor for touch-panel and other UV adhesive dispensing processes. One LED irradiation head is positioned above the conveyor, with a 70 mm effective irradiation width and a 405 ±5 nm wavelength.

View product
Vacuum Screen Exposure Machine ZKUE-3KA

UV Processing Equipment · ZKUE-3KA

Vacuum Screen Exposure Machine

The ZKUE-3KA exposes photosensitive screen-printing screens using a UV lamp and vacuum contact. The documented exposure area is 1000 × 1200 mm, with one 3 kW exposure lamp.

View product
AMOLED Lamination LED Curing System ZKUV-2215-2

UV Processing Equipment · ZKUV-2215-2

AMOLED Lamination LED Curing System

The ZKUV-2215-2 uses LED curing for AMOLED products after full lamination. Its system comprises product loading, curing, CIM and unloading units, combining the curing stage with product handling and identification.

View product
Silicone UV Surface Modification Conveyor ZKUV-3090

UV Processing Equipment · ZKUV-3090

Silicone UV Surface Modification Conveyor

The ZKUV-3090 is a UV surface modification conveyor for silicone products such as watch straps. The documented configuration has a 3200 mm UV section and a 500 mm stainless-steel conveyor.

View product
Silicone UV Surface Treatment Conveyor ZKUV-5090

UV Processing Equipment · ZKUV-5090

Silicone UV Surface Treatment Conveyor

The ZKUV-5090 is a UV surface treatment conveyor for silicone products such as watch straps. The archived configuration uses a stainless-steel mesh conveyor and a 5000 mm UV section.

View product
Silicone UV Surface Modification Conveyor ZKUV-6890

UV Processing Equipment · ZKUV-6890

Silicone UV Surface Modification Conveyor

The ZKUV-6890 is a UV surface modification conveyor for silicone products such as watch straps. The documented configuration has a 6400 mm UV section and a 500 mm stainless-steel conveyor.

View product
UV Ozone Surface Cleaning Conveyor ZKUV-O3UV

UV Processing Equipment · ZKUV-O3UV

UV Ozone Surface Cleaning Conveyor

The ZKUV-O3UV is a UV ozone surface cleaning conveyor for LCD and touch-panel production. The documented configuration uses ten 90 W low-pressure mercury lamps with 185/254 nm wavelengths and a 500 mm effective irradiation width.

View product
Parallel-Light UV Screen Exposure Machine ZKUE-4PL2

UV Processing Equipment · ZKUE-4PL2

Parallel-Light UV Screen Exposure Machine

The ZKUE-4PL2 is a parallel-light UV exposure machine for screens used in LCD, touch-panel and solar-industry processes. The documented configuration accepts a 1100 × 1300 mm screen and provides a 1000 × 1200 mm effective exposure area.

View product
Microcomputer-Controlled Screen Exposure Machine ZKUV-3KW

UV Processing Equipment · ZKUV-3KW

Microcomputer-Controlled Screen Exposure Machine

The ZKUV-3KW is a microcomputer-controlled screen exposure machine for photosensitive screen-printing screens. The archived configuration has one 3 kW exposure lamp and a maximum exposure size of 1000 × 1200 mm.

View product

Other Equipment Categories

Need a UV Processing Equipment configuration review?

Send the workpiece, process conditions, production requirement and available drawings for an initial review.

Send InquiryView Products
